Flammability

Coilcraft tests to the following standard for flammability:
IEC 60695-11-5   Fire Hazard Testing Standard: Test Flames- Needle-flame Test Method

This test conforms to the following automotive specification:
AEC-Q200  Automotive Electronics Council Stress Test Qualification for Passive Components

Comparison to UL94 Test:

The UL94 test applies a flame to a large bar of a single material.  The IEC test applies the flame the entire part.  The allowed burn time of 30 seconds is the same for both tests.  Therefore, the two tests are similar.
